CBM-7530B-224
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 75X30MM 24VDC WIRE
PDF
/
Inventory: 6951
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 30.00mm
Technical
Static Pressure 0.270 in H2O (67.3 Pa)
Voltage Range 10V~27.6VDC
Noise 33.9 dB(A)
Air Flow 9.6 CFM (0.269m3/min)
Fan Type Blower
Bearing Type Ball
RPM 2400 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, cURus, TUV
Current Rating (Amps) 0.080A
Voltage - Rated 24VDC
Power (Watts) 1.9W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Auto Restart
Size / Dimension Square/Rounded - 75mm Lx75mm H
Series CBM-75B
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Polybutylene Terephthalate (PBT)
Material - Frame Polybutylene Terephthalate (PBT)
Weight 0.191lb 86.64g
Supply Chain
Factory Lead Time 22 Weeks
