CBM-5015V-150
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 51.7X15MM 12VDC WIRE
PDF
/
Inventory: 8728
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 15.00mm
Technical
Static Pressure 0.670 in H2O (166.9 Pa)
Voltage Range 4.5V~13.8VDC
Noise 39.8 dB(A)
Air Flow 4.5 CFM (0.126m3/min)
Fan Type Blower
Bearing Type omniCOOL? Magnetic Sleeve
RPM 5000 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, cURus, TUV
Current Rating (Amps) 0.115A
Voltage - Rated 12VDC
Power (Watts) 1.38W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Auto Restart
Size / Dimension Square/Rounded - 51.7mm Lx51.6mm H
Series CBM-50V
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Blade Polybutylene Terephthalate (PBT)
Material - Frame Polybutylene Terephthalate (PBT)
Weight 0.067lb 30.39g
Supply Chain
Factory Lead Time 22 Weeks
