GDA1238-48BB

Comair Rotron
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL 120X38MM 48VDC WIRE
PDF
/
Inventory: 5355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Width 38.00mm
Height 120mm

Technical

Static Pressure 0.320 in H2O (79.7 Pa)
Voltage Range 24V~55.2VDC
Noise 40.8 dB(A)
Air Flow 128.0 CFM (3.58m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3000 RPM
Current Rating 350mA
Max Power Dissipation 16.8W
Current Rating (Amps) 0.350A
Voltage - Rated DC 48V
Power Rating 16.8W
Voltage - Rated 48VDC
Power (Watts) 16.8W
Min Operating Temperature -10°C
Max Operating Temperature 70°C
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Speed Sensor (Tach)
Size / Dimension Square - 120mm Lx120mm H
Series Gryphon
Published 2006

Physical

Weight 0.586lb 265.81g
Housing Material Thermoplastic
Package / Case Axial
Mount Flanges
