GDA1225-24BB
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X25MM 24VDC WIRE
PDF
/
Inventory: 3383
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Flanges
Package / Case Axial
Housing Material Thermoplastic
Weight 0.362lb 164.2g
Technical
Published 2006
Series Gryphon
Size / Dimension Square - 120mm Lx120mm H
Feature Speed Sensor (Tach)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Max Operating Temperature 70°C
Min Operating Temperature -10°C
Power (Watts) 8.4W
Voltage - Rated 24VDC
Power Rating 8.4W
Voltage - Rated DC 24V
Current Rating (Amps) 0.350A
Max Power Dissipation 8.4W
Current Rating 350mA
RPM 2400 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 69.0 CFM (1.93m3/min)
Noise 39.1 dB(A)
Voltage Range 12V~28VDC
Static Pressure 0.150 in H2O (37.4 Pa)
Dimensions
Height 120mm
Width 25.00mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
