19040433A
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X32MM 24V MC24B3NDN
PDF
/
Buying Options
Total Price: USD $31.35
Unit Price: USD $31.3544
≥1 USD $31.3544
≥10 USD $29.16804
≥100 USD $26.25128
≥500 USD $25.6762
Inventory: 350
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage Range 12V~28VDC
Noise 47.8 dB(A)
Air Flow 102.0 CFM (2.86m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3700 RPM
Life (Hours) 78000 hours
Lifetime @ Temp 78000 Hrs @ 40°C
Approval Agency UL
Current Rating 230mA
Max Power Dissipation 5.5W
Current Rating (Amps) 0.230A
Voltage - Rated 24VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Fan Performance Sensor (FPS)
Size / Dimension Square - 120mm Lx120mm H
Series Muffin
Published 2012
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Package / Case Axial
Supply Chain
Factory Lead Time 18 Weeks
