19039847A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN IMP MTR 175X68MM DD692712B1A
PDF
/
Inventory: 5755
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 68.00mm
Technical
Static Pressure 1.110 in H2O (276.5 Pa)
Voltage Range 6V~14VDC
Noise 59.8 dB(A)
Air Flow 275.0 CFM (7.70m3/min)
Fan Type Motorized Impellers
Bearing Type Ball
RPM 2400 RPM
Current Rating 2.1A
Max Power Dissipation 25.3W
Current Rating (Amps) 2.1A
Voltage - Rated 12VDC
Power (Watts) 25.3W
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Speed Sensor (Tach)
Size / Dimension Round - 175mm Dia
Series Diplomat
Published 2009
Physical
Material - Blade Metal
Material - Frame Aluminum
Weight 2.5lbs 1.1kg
