19039031A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN 127X38.1MM 24V GL24B7-E2
PDF
/
Inventory: 9221
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Material - Frame Zinc
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Size / Dimension Square - 127mm Lx127mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 24VDC
Current Rating (Amps) 0.630A
Max Power Dissipation 15W
Current Rating 630mA
Approval Agency UL
Lifetime @ Temp 82500 Hrs @ 50°C
RPM 3200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 150.0 CFM (4.20m3/min)
Noise 53.6 dB(A)
Voltage Range 12V~24VDC
Compliance
RoHS Status ROHS3 Compliant
