19032142A
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 120X32MM 24VDC MC24E3
PDF
/
Inventory: 4609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 32.00mm
Technical
Static Pressure 0.132 in H2O (32.9 Pa)
Voltage Range 12V~28VDC
Noise 39.7 dB(A)
Air Flow 60.0 CFM (1.68m3/min)
Fan Type Tubeaxial
Bearing Type Sleeve
RPM 2170 RPM
Current Rating 100mA
Max Power Dissipation 2.4W
Current Rating (Amps) 0.100A
Voltage - Rated 24VDC
Power (Watts) 2.4W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension Square - 120mm Lx120mm H
Series Muffin
Published 2003
Physical
Material - Blade Plastic
Material - Frame Plastic
Weight 0.529lb 239.95g
Package / Case Axial
Alternative Model
