17000194A
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXL 25X10MM CR0212MB-G50(GL)
PDF
/
Inventory: 4992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Operating Temperature 14~158°F -10°C~70°C
Size / Dimension Square - 25mm Lx25mm H
Feature Auto Restart, Locked Rotor Sensor
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination 2 Wire Leads
Power (Watts) 720mW
Voltage - Rated 12VDC
Current Rating (Amps) 0.060A
Approval Agency CE, cUL, TUV, UL
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 10000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 2.1 CFM (0.059m3/min)
Noise 23.0 dB(A)
Static Pressure 0.150 in H2O (37.4 Pa)
Dimensions
Width 10.00mm
Alternative Model
