TSC2302IRGZR
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive Touchscreen Controller 12b -40C~85C 7mm 3.6V
PDF
/
Buying Options
Total Price: USD $7.07
Unit Price: USD $7.07275
≥1 USD $7.07275
≥10 USD $5.80355
≥100 USD $5.6221
≥500 USD $5.44065
≥1000 USD $5.2592
Inventory: 7805
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1mm
Technical
Voltage Reference External Internal
Touchscreen 4 Wire Resistive
Resolution (Bits) 12 b
Consumer IC Type CONSUMER CIRCUIT
Number of Bits 12
Interface I2S
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Pin Count 48
Base Part Number TSC2302
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
Technology CMOS
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 137.410139mg
Number of Pins 48
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
