TSC2302IRGZ
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive Touchscreen Controller 12b -40C~85C 7mm 3.6V
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1477
≥1 USD $4.1477
≥10 USD $3.40385
≥100 USD $3.29745
≥500 USD $3.19105
≥1000 USD $3.08465
Inventory: 8604
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Number of Pins 48
Weight 137.410139mg
Manufacturer Package Identifier RGZ(S-PVQFN-N48)
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 48
Subcategory Other Consumer ICs
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position QUAD
Number of Functions 1
Terminal Pitch 0.5mm
Base Part Number TSC2302
Pin Count 48
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Interface I2S
Number of Bits 12
Consumer IC Type CONSUMER CIRCUIT
Resolution (Bits) 12 b
Touchscreen 4 Wire Resistive
Voltage Reference External Internal
Dimensions
Length 7mm
Width 7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
