TSC2111IRGZR
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive Touchscreen Controller 125ksps 12b -40C~85C 7mm
PDF
/
Buying Options
Total Price: USD $4.76
Unit Price: USD $4.7608
≥1 USD $4.7608
Inventory: 37738
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
Voltage Reference External Internal
Touchscreen 4 Wire Resistive
Resolution (Bits) 12 b
Number of D/A Converters 2
Number of A/D Converters 1
Sampling Rate 125 ksps
Output Power 0.4W
Number of Bits 12
Nominal Supply Current 68μA
Operating Supply Current 68μA
Interface SPI
Number of Channels 1
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number TSC2111
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Subcategory Other Consumer ICs
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 137.410139mg
Number of Pins 48
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
