TSC2100IDAR
RoHS
RoHS compliant
RoHS compliantPackage 32-TSSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive touch screen controller 12b -40C~85C 11mm 780muA
PDF
/
Inventory: 9071
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 6.1mm
Length 11mm
Height Seated (Max) 1.2mm
Technical
Voltage Reference External Internal
Touchscreen 4 Wire Resistive
Resolution (Bits) 12 b
Consumer IC Type CONSUMER CIRCUIT
Number of Bits 12
Operating Supply Current 780μA
Interface I2S, SPI
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 1.83.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Pin Count 32
Base Part Number TSC2100
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~3.6V
Technology CMOS
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Additional Feature IT ALSO REQUIRES 1.525V TO 1.95V SUPPLY
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 173.300635mg
Number of Pins 32
Package / Case 32-TSSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
