LM8500IMT9B/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.240, 6.10mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete 4Wire Resistive DUAL Touchscreen Controller 10b 0C~70C 1.2mm 11.5mA
PDF
/
Buying Options
Total Price: USD $7.83
Unit Price: USD $7.8299
≥1 USD $7.8299
≥10 USD $6.4239
≥100 USD $6.22345
≥500 USD $6.023
≥1000 USD $5.8216
Inventory: 7692
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.15mm
Width 6.1mm
Length 12.5mm
Height 1.2mm
Technical
Touchscreen 4 Wire Resistive
Resolution (Bits) 10 b
Consumer IC Type CONSUMER CIRCUIT
Data Rate 38.4 kbps
Number of Bits 10
Nominal Supply Current 11.5mA
Operating Supply Current 11.5mA
Interface UART
Supply Voltage-Min (Vsup) 2.7V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Base Part Number LM8500
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Subcategory Other Consumer ICs
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 48
Package / Case 48-TFSOP (0.240, 6.10mm Width)
Mounting Type Surface Mount
Mount Surface Mount
