SX8654ICSTRT
RoHS
/
Package 19-UFBGA, WLCSP
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
RoHS Compliant Obsolete Internal 4or 5Wire Resistive Touchscreen Controller 12b -40C~85C 2.07mm 120muA
PDF
/
Inventory: 9865
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 19-UFBGA, WLCSP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2017
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 19
HTS Code 8542.39.00.01
Voltage - Supply 2.3V~3.6V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number SX865
JESD-30 Code R-PBGA-B19
Interface I2C, Serial
Current - Supply 120μA
Telecom IC Type TELECOM CIRCUIT
Resolution (Bits) 12 b
Touchscreen 4 or 5 Wire Resistive
Voltage Reference Internal
Dimensions
Height Seated (Max) 0.604mm
Length 2.07mm
Width 2.07mm
Compliance
RoHS Status RoHS Compliant
