AD7889-1ACBZ-RL7
RoHS
RoHS compliant
RoHS compliantPackage 12-UFBGA, WLCSP
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External 4Wire Resistive Touchscreen Controller 0.105MHz 12b -40C~85C 2.005mm
PDF
/
Buying Options
Total Price: USD $97.38
Unit Price: USD $97.37595
≥1 USD $97.37595
≥10 USD $94.23525
≥100 USD $91.0936
≥500 USD $81.67055
Inventory: 1106
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.505mm
Length 2.005mm
Height Seated (Max) 0.65mm
Technical
Voltage Reference External
Touchscreen 4 Wire Resistive
Resolution (Bits) 12 b
Analog Input Voltage-Max 3.6V
Sample and Hold / Track and Hold TRACK
Linearity Error-Max (EL) 0.0732%
Output Bit Code BINARY
Number of Analog In Channels 2
Sampling Rate 0.105 MHz
Converter Type ADC, SUCCESSIVE APPROXIMATION
Current - Supply 10nA
Number of Bits 12
Interface I2C, Serial
JESD-30 Code R-PBGA-B12
Pin Count 12
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 2.6V
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.6V~3.6V
Terminal Finish MATTE TIN
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 12-UFBGA, WLCSP
Mounting Type Surface Mount
