AD7877ACP-500RL7
RoHS
/
Package 32-VFQFN Exposed Pad, CSP
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
Non-RoHS Compliant Obsolete External Internal QUAD Touchscreen Controller 12b -40C~85C 5mm 1muA
PDF
/
Buying Options
Total Price: USD $2.88
Unit Price: USD $2.8776
≥1 USD $2.8776
Inventory: 1387
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 32-VFQFN Exposed Pad, CSP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Terminal Finish TIN LEAD
Additional Feature FUNCTIONALLY IT OPERATES FROM 2.2 TO 5.25V
Voltage - Supply 2.7V~5.25V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 32
JESD-30 Code S-XQCC-N32
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Current - Supply 1μA
Consumer IC Type CONSUMER CIRCUIT
Resolution (Bits) 12 b
Voltage Reference External Internal
Dimensions
Height Seated (Max) 1mm
Length 5mm
Width 5mm
Compliance
RoHS Status Non-RoHS Compliant
