AD7873BRQZ-REEL7
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive Touchscreen Controller 12b -40C~85C 4.9022mm 3.6V
PDF
/
Buying Options
Total Price: USD $23.76
Unit Price: USD $23.7576
≥1 USD $23.7576
≥10 USD $19.49305
≥100 USD $18.8841
≥500 USD $18.27515
≥1000 USD $17.6662
Inventory: 7510
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish MATTE TIN
Additional Feature FUNCTIONALLY IT OPERATES FROM 2.2 TO 5.25V
Voltage - Supply 2.2V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.635mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.2V
Interface Serial
Consumer IC Type CONSUMER CIRCUIT
Resolution (Bits) 12 b
Touchscreen 4 Wire Resistive
Voltage Reference External Internal
Dimensions
Height Seated (Max) 1.7526mm
Length 4.9022mm
Width 3.9116mm
Compliance
RoHS Status ROHS3 Compliant
