AD7873ACPZ-REEL7
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad, CSP
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive Touchscreen Controller 12b -40C~85C 4mm 3.6V
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.489
≥1 USD $2.489
≥10 USD $2.0425
≥100 USD $1.97885
≥500 USD $1.9152
≥1000 USD $1.85155
Inventory: 1239
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Voltage Reference External Internal
Touchscreen 4 Wire Resistive
Resolution (Bits) 12 b
Consumer IC Type CONSUMER CIRCUIT
Interface Serial
Supply Voltage-Min (Vsup) 2.2V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status COMMERCIAL
JESD-30 Code S-XQCC-N16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.2V~5.25V
Additional Feature FUNCTIONALLY IT OPERATES FROM 2.2 TO 5.25V
Terminal Finish MATTE TIN
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 16-VQFN Exposed Pad, CSP
Mounting Type Surface Mount
