AR1011T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
AR1011 Tin UART 20-VFQFN Exposed Pad touch screen controller 5.25V 17mA 4mm -40C~85C
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.498449
≥1 USD $2.498449
≥200 USD $0.967607
≥500 USD $0.933472
≥1000 USD $0.916404
Inventory: 1682
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2009
Series mTouch?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
HTS Code 8542.39.00.01
Voltage - Supply 2.5V~5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AR1011
Pin Count 20
JESD-30 Code S-PQCC-N20
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 2.5V
Interface UART
Analog IC - Other Type ANALOG CIRCUIT
Operating Supply Current 17mA
Nominal Supply Current 17mA
Resolution (Bits) 10 b
Touchscreen 4, 5, or 8 Wire Resistive
Dimensions
Height Seated (Max) 1mm
Length 4mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
