AD7873BRQZ
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Touch Screen Controllers
Description
ROHS3Compliant Obsolete External Internal 4Wire Resistive Touchscreen Controller 125ksps 12b -40C~85C 4.9022mm
PDF
/
Buying Options
Total Price: USD $3.04
Unit Price: USD $3.0362
≥1 USD $3.0362
≥10 USD $2.49185
≥100 USD $2.41395
≥500 USD $2.33605
≥1000 USD $2.25815
Inventory: 2550
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 4.9022mm
Technical
Voltage Reference External Internal
Touchscreen 4 Wire Resistive
Resolution (Bits) 12 b
Consumer IC Type CONSUMER CIRCUIT
Input Capacitance 37pF
Integral Nonlinearity (INL) 1 LSB
Sampling Rate 125 ksps
Max Input Voltage 3.3V
Min Input Voltage 1V
Supply Current-Max 0.38mA
Number of Bits 12
Power Dissipation 1.4mW
Interface Serial
Number of Channels 6
Supply Voltage-Min (Vsup) 2.2V
Polarity Unipolar
Number of Elements 1
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 16
Base Part Number AD7873
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.2V~5.25V
Additional Feature FUNCTIONALLY IT OPERATES FROM 2.2 TO 5.25V
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Tin
