TLC5602CDWRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
IC DAC 8BIT VIDEO LOW-PWR 20SOIC
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.4149
≥1 USD $2.4149
≥10 USD $1.9817
≥100 USD $1.91995
≥500 USD $1.8582
≥1000 USD $1.7955
Inventory: 1119
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Conversion Rate 30 Msps
Number of Converters 1
Input Bit Code BINARY
Linearity Error-Max (EL) 0.2%
Power Consumption 80mW
Settling Time 30 ns
Sampling Rate 30 Msps
Resolution 1 B
Supply Type Analog, Digital
Converter Type D/A CONVERTER
Number of Bits 8
Nominal Supply Current 16mA
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Interface Parallel
Temperature Grade COMMERCIAL
Power Supplies 5V
Operating Supply Voltage 5V
Output Type Voltage
Pin Count 20
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Converters
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Tape and Reel
Physical
Weight 537.308512mg
Number of Pins 20
Surface Mount YES
Package / Case SOIC
