DAC8534IPWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
16-TSSOP (0.173 4.40mm Width) Voltage - Buffered String DAC DAC8534 digital to analog converter 5.5V 10mus 93ksps 1LSB
PDF
/
Buying Options
Total Price: USD $20.2
Unit Price: USD $20.196528
≥1 USD $20.196528
≥10 USD $19.355387
≥100 USD $21.3408
≥500 USD $20.653
≥1000 USD $19.96425
Inventory: 8
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Spurious-free dynamic range (SFDR) 69 dB
Number of DAC Channels 4
Differential Nonlinearity 1 LSB
Input Format SERIAL
Signal to Noise Ratio (SNR) 94 dB
INL/DNL (LSB) -, ±1 (Max)
Conversion Rate 93 ksps
Input Bit Code BINARY
Integral Nonlinearity (INL) 64 LSB
Linearity Error-Max (EL) 0.0987%
Power Consumption 2.7mW
Settling Time 10μs
Voltage - Supply, Digital 2.7V~5.5V
Voltage - Supply, Analog 2.7V~5.5V
Sampling Rate 93 ksps
Resolution 2 B
Differential Output No
Data Interface SPI, DSP
Reference Type External
Supply Type Single
Converter Type D/A CONVERTER
Architecture String DAC
Number of Bits 16
Nominal Supply Current 950μA
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Interface SPI
Power Supplies 3/5V
Polarity Unipolar
Output Type Voltage - Buffered
Pin Count 16
Base Part Number DAC8534
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Converters
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Weight 62.99264mg
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
