DAC8164IDPWR
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
Surface Mount DUAL GULL WING External Internal Digital to Analog Converter -40C~105C 1.6mA 5mm 1LSB
PDF
/
Buying Options
Total Price: USD $11.37
Unit Price: USD $11.37018
≥1 USD $11.37018
≥10 USD $10.726589
≥100 USD $10.119422
≥500 USD $9.546628
≥1000 USD $9.006252
Inventory: 1108
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 5mm
Height Seated (Max) 1.2mm
Technical
Spurious-free dynamic range (SFDR) 79 dB
Number of DAC Channels 4
Differential Nonlinearity 1 LSB
Analog Output Voltage-Max 2.5005V
Signal to Noise Ratio (SNR) 87 dB
INL/DNL (LSB) ±1, ±0.3
Input Bit Code BINARY
Integral Nonlinearity (INL) 2 LSB
Linearity Error-Max (EL) 0.0122%
Power Consumption 2.9mW
Settling Time 10μs
Voltage - Supply, Digital 2.7V~5.5V
Voltage - Supply, Analog 2.7V~5.5V
Resolution 1.75 B
Differential Output No
Data Interface SPI, DSP
Reference Type External, Internal
Supply Type Single
Converter Type D/A CONVERTER
Architecture String DAC
Supply Current-Max 1.6mA
Number of Bits 14
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Interface SPI, Serial
Power Supplies 3/5V
Polarity Unipolar
Output Type Voltage - Buffered
Pin Count 16
Base Part Number DAC8164
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Converters
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Weight 62.99264mg
Number of Pins 16
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Contact Plating Gold
