DAC7801KP
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
Through Hole DUAL External ROHS3Compliant Digital to Analog Converter -40C~85C 4.57mm 1LSB 1.25Msps
PDF
/
Buying Options
Total Price: USD $53.06
Unit Price: USD $53.0575
≥1 USD $53.0575
≥10 USD $43.5347
≥100 USD $42.1743
≥500 USD $40.8139
≥1000 USD $39.4535
Inventory: 1170
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 6.73mm
Length 31.64mm
Height 4.57mm
Technical
Differential Nonlinearity 1 LSB
INL/DNL (LSB) ±1 (Max), ±1 (Max)
Conversion Rate 1.25 Msps
Number of Converters 2
Input Bit Code BINARY
Integral Nonlinearity (INL) 1 LSB
Power Consumption 1mW
Settling Time 800ns
Voltage - Supply, Analog 5V
Sampling Rate 1.25 Msps
Resolution 1.5 B
Differential Output No
Data Interface Parallel
Reference Type External
Supply Type Single
Converter Type D/A CONVERTER
Architecture Multiplying DAC
Number of Bits 12
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Power Supplies 5V
Operating Supply Voltage 5V
Output Type Current - Unbuffered
Pin Count 24
Base Part Number DAC7801
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Technology CMOS
Subcategory Other Converters
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 24
Surface Mount NO
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
