DAC104S085CIMM
RoHS
/
Package 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
IC DAC 10BIT V-OUT 10VSSOP
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.95355
≥1 USD $2.95355
≥10 USD $2.42345
≥100 USD $2.34745
≥500 USD $2.2724
≥1000 USD $2.1964
Inventory: 9463
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Converters
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Base Part Number DAC104S085
Pin Count 10
Output Type Voltage - Buffered
Operating Supply Voltage 5V
Polarity Unipolar
Interface SPI, Serial
Max Supply Voltage 5.5V
Min Supply Voltage 2.7V
Nominal Supply Current 500μA
Number of Bits 10
Architecture String DAC
Converter Type D/A CONVERTER
Supply Type Single
Reference Type External
Data Interface SPI, DSP
Differential Output No
Resolution 1.25 B
Voltage - Supply, Analog 2.7V~5.5V
Voltage - Supply, Digital 2.7V~5.5V
Settling Time 6μs
Power Consumption 1.1mW
Linearity Error-Max (EL) 0.1953%
Integral Nonlinearity (INL) 2 LSB
Input Bit Code BINARY
Number of Converters 4
INL/DNL (LSB) ±0.7, +0.08
Dimensions
Height 860μm
Length 3mm
Width 3mm
Compliance
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
