MAX503EAG
RoHS
/
Package 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
24-SSOP (0.209 5.30mm Width) Voltage - Buffered R-2R R-PDSO-G24 digital to analog converter 4.6V 25mus (Typ) 8.2mm -40C~85C
PDF
/
Inventory: 6704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.29mm
Length 8.2mm
Technical
Analog Output Voltage-Min -4.6V
Analog Output Voltage-Max 4.6V
Number of D/A Converters 1
Negative Supply Voltage-Nom -5V
INL/DNL (LSB) ±0.5 (Max), ±1 (Max)
Input Bit Code BINARY, OFFSET BINARY
Linearity Error-Max (EL) 0.0488%
Settling Time 25μs (Typ)
Voltage - Supply, Digital 5V
Voltage - Supply, Analog ±5V
Differential Output No
Data Interface Parallel
Reference Type External, Internal
Converter Type D/A CONVERTER
Architecture R-2R
Number of Bits 10
Output Type Voltage - Buffered
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G24
Pin Count 24
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 24-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
