AD7224LR-18
RoHS
/
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
18-SOIC (0.295 7.50mm Width) R-PDSO-G18 TIN LEAD D/A CONVERTER digital to analog converter -5V 11.55mm 85C
PDF
/
Buying Options
Total Price: USD $10.1
Unit Price: USD $10.1024
≥1 USD $10.1024
Inventory: 1126
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 18-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 15V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 18
JESD-30 Code R-PDSO-G18
Qualification Status Not Qualified
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Temperature Grade INDUSTRIAL
Number of Bits 8
Converter Type D/A CONVERTER
Linearity Error-Max (EL) 0.1953%
Input Bit Code BINARY
Negative Supply Voltage-Nom -5V
Input Format PARALLEL, 8 BITS
Dimensions
Height Seated (Max) 2.65mm
Length 11.55mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
