MAX537AEWE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
16-SOIC (0.295 7.50mm Width) Voltage - Buffered R-2R MAX537 digital to analog converter 2.5V 5mus (Typ) 0.5LSB 10.3mm
PDF
/
Buying Options
Total Price: USD $53.73
Unit Price: USD $53.7328
≥1 USD $53.7328
≥10 USD $50.4768
≥100 USD $48.848422
≥500 USD $45.266241
Inventory: 39
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 10.3mm
Height Seated (Max) 2.65mm
Technical
Number of DAC Channels 4
Analog Output Voltage-Max 2.5V
Negative Supply Voltage-Nom -5V
INL/DNL (LSB) ±0.15, ±1 (Max)
Input Bit Code BINARY
Integral Nonlinearity (INL) 0.5 LSB
Settling Time 5μs (Typ)
Voltage - Supply, Analog ±5V
Resolution 1.5 B
Differential Output No
Data Interface SPI
Reference Type External
Supply Type Dual
Converter Type D/A CONVERTER
Architecture R-2R
Number of Bits 12
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface SPI, Serial
Power Supplies +-5V
Output Type Voltage - Buffered
Pin Count 16
Base Part Number MAX537
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology CMOS
Max Power Dissipation 762mW
Subcategory Other Converters
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
