MAX509BCAP+T
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
20-SSOP (0.209 5.30mm Width) Voltage - Buffered R-2R MAX509 digital to analog converter 5V 6mus (Typ) 800mW 7.2mm
PDF
/
Inventory: 2432
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn)
Subcategory Other Converters
Max Power Dissipation 800mW
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number MAX509
Pin Count 20
Output Type Voltage - Buffered
Power Supplies 5/+-5V
Interface SPI, Serial
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Number of Bits 8
Supply Current-Max 10mA
Architecture R-2R
Converter Type D/A CONVERTER
Supply Type Dual
Reference Type External
Data Interface SPI
Differential Output No
Resolution 1 B
Voltage - Supply, Analog ±5V
Voltage - Supply, Digital 5V
Settling Time 6μs (Typ)
Linearity Error-Max (EL) 0.037%
Input Bit Code BINARY
INL/DNL (LSB) -, ±1 (Max)
Negative Supply Voltage-Nom -5V
Number of D/A Converters 4
Analog Output Voltage-Max 5V
Analog Output Voltage-Min -5V
Dimensions
Height Seated (Max) 1.99mm
Length 7.2mm
Width 5.29mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
