LTC2637CMS-HMI8#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TFSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital to Analog Converters (DAC)
Description
SERIAL Surface Mount DUAL GULL WING Digital to Analog Converter 0C~70C 1.5mA 4.039mm 3.9mus (Typ)
PDF
/
Buying Options
Total Price: USD $4.69
Unit Price: USD $4.688366
≥1 USD $4.688366
≥200 USD $1.814428
≥500 USD $1.751409
≥1000 USD $1.719899
Inventory: 1217
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4.039mm
Height Seated (Max) 1.1mm
Technical
Analog Output Voltage-Max 4.096V
Input Format SERIAL
INL/DNL (LSB) ±0.05, ±0.5 (Max)
Input Bit Code BINARY
Linearity Error-Max (EL) 0.1953%
Settling Time 3.9μs (Typ)
Voltage - Supply, Analog 5V
Differential Output No
Data Interface I2C
Reference Type External, Internal
Converter Type D/A CONVERTER
Supply Current-Max 1.5mA
Number of Bits 8
Power Supplies 5V
Output Type Voltage - Buffered
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number LTC2637
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 8
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Converters
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-TFSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
