X9314WS
RoHS
/
Package /
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
Non-RoHS Compliant GULL WING COMMERCIAL LOGARITHMIC Digital Potentiometer 20% 70C 4.9mm 10000Ohm
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.4992
≥1 USD $2.4992
Inventory: 205
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Resistance Tolerance-Max 20%
Control Interface INCREMENT/DECREMENT
Resistance Law LOGARITHMIC
Resistor Terminal Voltage-Min -5V
Resistor Terminal Voltage-Max 5V
Total Resistance 10000Ohm
Converter Type DIGITAL POTENTIOMETER
Temperature Grade COMMERCIAL
Operating Temperature (Max) 70°C
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Additional Feature NONVOLATILE MEMORY
Terminal Finish TIN LEAD
Number of Positions 32
Temperature Coefficient 600 ppm/°C
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Physical
Surface Mount YES
