DS1854B-050
RoHS
/
Package 16-LBGA, CSPBGA
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
IT CAN ALSO OPERATE FROM A 5V NOMINAL SUPPLY Temperature Sensor I2C S-PBGA-B16 digital potentiometer 3.3V 50kOhm 4mm -40C~95C
PDF
/
Inventory: 2556
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-LBGA, CSPBGA
Surface Mount YES
Technical
Operating Temperature -40°C~95°C
Packaging Tray
Tolerance ±20%
Feature Temperature Sensor
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Resistance 50kOhm
Terminal Finish NOT SPECIFIED
Additional Feature IT CAN ALSO OPERATE FROM A 5V NOMINAL SUPPLY
Voltage - Supply 3V~5.5V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 16
JESD-30 Code S-PBGA-B16
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 3V
Configuration Rheostat
Interface I2C
Number of Circuits 2
Analog IC - Other Type ANALOG CIRCUIT
Memory Type Non-Volatile
Taper Linear
Number of Taps 256
Temperature Coefficient (Typ) 50ppm/°C
Dimensions
Height Seated (Max) 1.5mm
Length 4mm
Width 4mm
Compliance
RoHS Status Non-RoHS Compliant
