CAT5114ZI-00-G
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
ROHS3Compliant GULL WING Surface Mount Linear Digital Potentiometer ±20% -40C~85C 3mm 100kOhm
PDF
/
Buying Options
Total Price: USD $2.29
Unit Price: USD $2.293636
≥1 USD $2.293636
≥192 USD $0.915091
≥480 USD $0.884895
≥960 USD $0.870453
Inventory: 2854
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Temperature Coefficient (Typ) 300ppm/°C
Resistor Terminal Voltage-Max 3V
Resistance - Wiper (Ω) (Typ) 400
Total Resistance 100000Ohm
Number of Taps 32
Taper Linear
Memory Type Non-Volatile
Number of Circuits 1
Interface Up/Down (U/D, INC, CS)
Configuration Potentiometer
Qualification Status COMMERCIAL
JESD-30 Code S-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.5V~6V
Additional Feature NONVOLATILE MEMORY
Terminal Finish NICKEL PALLADIUM GOLD
Number of Positions 32
Resistance 100kOhm
Temperature Coefficient 300 ppm/°C
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Tolerance ±20%
Series CAT5114
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
