AD5251BRUZ10
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
ROHS3Compliant CMOS GULL WING Surface Mount Digital Potentiometer ±20% -40C~105C 5mm 10kOhm
PDF
/
Inventory: 8560
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 5mm
Technical
Temperature Coefficient (Typ) 650ppm/°C
Resistance - Wiper (Ω) (Typ) 200
Total Resistance 10000Ohm
Number of Taps 64
Negative Supply Voltage-Nom -2.5V
Taper Linear
Bandwidth 0.4 kHz
Memory Type Non-Volatile
Number of Circuits 2
Interface I2C
Configuration Potentiometer
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G14
Pin Count 14
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Terminal Pitch 0.65mm
Supply Voltage 2.5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V ±2.25V~2.75V
Technology CMOS
Additional Feature NONVOLATILE MEMORY; DEVICE SUPPORTS DUAL SUPPLY OPERATION
Terminal Finish MATTE TIN
Number of Positions 64
Resistance 10kOhm
Temperature Coefficient 650 ppm/°C
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Selectable Address
JESD-609 Code e3
Tolerance ±20%
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
