CAT523L
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
RoHS Compliant THROUGH-HOLE INDUSTRIAL PDIP digital potentiometer 85C 600muA 19.05mm 24kOhm
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.3112
≥1 USD $1.3112
Inventory: 1144
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.62mm
Length 19.05mm
Height Seated (Max) 5.33mm
Technical
Nominal Supply Current 600μA
Analog IC - Other Type ANALOG CIRCUIT
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form THROUGH-HOLE
Terminal Position DUAL
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Resistance 24kOhm
Number of Terminations 14
JESD-609 Code e3
Physical
Surface Mount NO
Package / Case PDIP
