MCP4632T-502E/UN
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4632 Selectable Address I2C e3 digital potentiometer 5V 5kOhm 0.5mm 2.5muA
PDF
/
Inventory: 6933
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Resistance - Wiper (Ω) (Typ) 75
Number of Taps 129
Taper Linear
Converter Type DIGITAL POTENTIOMETER
Memory Type Volatile
Nominal Supply Current 2.5μA
Number of Circuits 2
Interface I2C
Configuration Rheostat
Operating Supply Voltage 5V
Pin Count 10
Base Part Number MCP4632
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Subcategory Digital Potentiometers
Terminal Finish Matte Tin (Sn) - annealed
Number of Positions 128
Resistance 5kOhm
Temperature Coefficient 150 ppm/°C
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Selectable Address
JESD-609 Code e3
Tolerance ±20%
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 10
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
