MCP4431T-503E/ML
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4431 Selectable Address I2C e3 digital potentiometer 3/5V 50kOhm 0.5mm -40C~125C
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.256445
≥1 USD $1.256445
≥200 USD $0.487086
≥500 USD $0.470018
≥1000 USD $0.460828
Inventory: 6816
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Temperature Coefficient (Typ) 150ppm/°C
Resistance - Wiper (Ω) (Typ) 75
Number of Taps 129
Taper Linear
Memory Type Volatile
Number of Circuits 4
Interface I2C
Configuration Potentiometer
Power Supplies 3/5V
Qualification Status Not Qualified
Base Part Number MCP4431
Terminal Pitch 0.5mm
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Resistance 50kOhm
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Selectable Address
JESD-609 Code e3
Tolerance ±20%
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
