MCP4331-104E/ML
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4331 SPI e3 Potentiometer digital potentiometer 0.1kHz 3/5V 100kOhm 950mum
PDF
/
Buying Options
Total Price: USD $45.64
Unit Price: USD $45.6418
≥1 USD $45.6418
≥10 USD $37.44995
≥100 USD $36.27955
≥500 USD $35.10915
≥1000 USD $33.93875
Inventory: 551
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2010
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Temperature Coefficient 150 ppm/°C
Resistance 100kOhm
Number of Positions 129
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 2.7V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP4331
Pin Count 20
Qualification Status Not Qualified
Power Supplies 3/5V
Configuration Potentiometer
Interface SPI
Number of Circuits 4
Memory Type Volatile
Bandwidth 0.1 kHz
Taper Linear
Number of Taps 129
Total Resistance 100000Ohm
Resistance - Wiper (Ω) (Typ) 75
Resistor Terminal Voltage-Max 5.5V
Dimensions
Height 950μm
Length 4mm
Width 4mm
Compliance
RoHS Status ROHS3 Compliant
