MCP4251T-104E/ML
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4251 SPI e3 Potentiometer digital potentiometer 0.1kHz 5V 100kOhm 4mm
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.86914
≥1 USD $0.86914
≥200 USD $0.336102
≥500 USD $0.324286
≥1000 USD $0.319035
Inventory: 1641
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Resistor Terminal Voltage-Max 5V
Resistance - Wiper (Ω) (Typ) 75
Total Resistance 100000Ohm
Number of Taps 257
Taper Linear
Bandwidth 0.1 kHz
Memory Type Volatile
Nominal Supply Current 1mA
Number of Circuits 2
Interface SPI
Configuration Potentiometer
Operating Supply Voltage 5V
Pin Count 16
Base Part Number MCP4251
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Positions 256
Resistance 100kOhm
Temperature Coefficient 150 ppm/°C
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Package / Case 16-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
