MCP4231T-503E/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4231 SPI e3 Potentiometer digital potentiometer 0.2kHz 5V 50kOhm 5mm
PDF
/
Inventory: 2745
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.4mm
Length 5mm
Technical
Resistor Terminal Voltage-Max 5V
Resistance - Wiper (Ω) (Typ) 75
Total Resistance 50000Ohm
Number of Taps 129
Taper Linear
Bandwidth 0.2 kHz
Memory Type Volatile
Nominal Supply Current 1mA
Number of Circuits 2
Interface SPI
Configuration Potentiometer
Operating Supply Voltage 5V
Pin Count 14
Base Part Number MCP4231
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Positions 128
Resistance 50kOhm
Temperature Coefficient 150 ppm/°C
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
