MCP4131-503E/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4131 SPI e3 Potentiometer digital potentiometer 0.2kHz 5V 50kOhm 3mm
PDF
/
Inventory: 5757
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
Resistor Terminal Voltage-Max 5V
Resistance - Wiper (Ω) (Typ) 75
Total Resistance 50000Ohm
Number of Taps 129
Taper Linear
Bandwidth 0.2 kHz
Memory Type Volatile
Nominal Supply Current 1mA
Number of Circuits 1
Interface SPI
Configuration Potentiometer
Operating Supply Voltage 5V
Pin Count 8
Base Part Number MCP4131
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Positions 128
Resistance 50kOhm
Temperature Coefficient 150 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Published 2007
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
