DS1869S-50
RoHS
/
Package 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
Non-RoHS Compliant GULL WING Surface Mount Linear Digital Potentiometer ±20% -40C~85C 5.285mm 50kOhm
PDF
/
Inventory: 2718
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 5.285mm
Technical
Temperature Coefficient (Typ) 750ppm/°C
Resistance - Wiper (Ω) (Typ) 400
Total Resistance 50000Ohm
Number of Taps 64
Negative Supply Voltage-Nom -1.5V
Taper Linear
Memory Type Non-Volatile
Number of Circuits 1
Interface Pushbutton, Serial
Configuration Potentiometer
Power Supplies +-2.2/+-8V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number DS1869
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 1.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply ±2.7V~8V
Additional Feature ALSO OPERATE WITH SINGLE 5V SUPPLY
Terminal Finish Matte Tin (Sn)
Number of Positions 64
Resistance 50kOhm
Temperature Coefficient 750 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Tolerance ±20%
Series Dallastat?
Published 1999
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
