DS1867-10
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
Non-RoHS Compliant Tin/Lead (Sn/Pb) Through Hole Linear Digital Potentiometer ±20% -40C~85C 19.05mm 10kOhm
PDF
/
Buying Options
Total Price: USD $53.7
Unit Price: USD $53.6959
≥1 USD $53.6959
≥10 USD $44.05815
≥100 USD $42.6816
≥500 USD $41.30505
≥1000 USD $39.92755
Inventory: 562
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead, Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Length 19.05mm
Technical
Resistor Terminal Voltage-Min -5V
Temperature Coefficient (Typ) 750ppm/°C
Resistor Terminal Voltage-Max 5.5V
Resistance - Wiper (Ω) (Typ) 400
Total Resistance 10000Ohm
Number of Taps 256
Negative Supply Voltage-Nom -5V
Taper Linear
Bandwidth 1 kHz
Memory Type Non-Volatile
Number of Circuits 2
Interface Serial
Configuration Potentiometer
Power Supplies 5V
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T14
Pin Count 14
Base Part Number DS1867
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 5V
Terminal Finish Tin/Lead (Sn/Pb)
Number of Positions 256
Resistance 10kOhm
Temperature Coefficient 750 ppm/°C
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Cascade Pin
JESD-609 Code e0
Tolerance ±20%
Published 1999
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
