DS1804U-010
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
Non-RoHS Compliant Single GULL WING Surface Mount Digital Potentiometer ±20% -40C~85C 400muA 950mum
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 17752
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 3.05mm
Length 3.05mm
Height 950μm
Technical
Resistor Terminal Voltage-Min -0.5V
Resistor Terminal Voltage-Max 5.5V
Resistance - Wiper (Ω) (Typ) 400
Total Resistance 10000Ohm
Number of Taps 100
Taper Linear
Bandwidth 1 kHz
Supply Type Single
Max Supply Current 400μA
Memory Type Non-Volatile
Operating Supply Current 400μA
Number of Circuits 1
Interface Up/Down (U/D, INC, CS)
Configuration Potentiometer
Power Supplies 3/5V
Pin Count 8
Base Part Number DS1804
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Number of Positions 100
Resistance 10kOhm
Temperature Coefficient 750 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Tolerance ±20%
Published 2004
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Contact Plating Tin
