DS1803E-100
RoHS
/
Package 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
Non-RoHS Compliant CMOS GULL WING Surface Mount Digital Potentiometer ±20% -40C~85C 200muA 950mum
PDF
/
Buying Options
Total Price: USD $2.63
Unit Price: USD $2.62675
≥1 USD $2.62675
≥10 USD $2.15555
≥100 USD $2.0881
≥500 USD $2.02065
≥1000 USD $1.9532
Inventory: 1309
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2001
Tolerance ±20%
JESD-609 Code e0
Feature Selectable Address
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Temperature Coefficient 750 ppm/°C
Resistance 100kOhm
Number of Positions 256
Terminal Finish Tin/Lead (Sn/Pb)
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 2
Supply Voltage 3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number DS1803
Pin Count 14
Operating Supply Voltage 5V
Configuration Potentiometer
Interface I2C
Number of Circuits 2
Nominal Supply Current 200μA
Memory Type Volatile
Bandwidth 0.1 kHz
Taper Linear
Number of Taps 256
Total Resistance 100000Ohm
Resistance - Wiper (Ω) (Typ) 400
Dimensions
Height 950μm
Length 5.1mm
Width 4.5mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
