AD5220BRMZ50
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
ROHS3Compliant CMOS GULL WING Surface Mount Digital Potentiometer ±30% -40C~85C 15muA 1.1mm
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.45445
≥1 USD $1.45445
≥10 USD $1.1932
≥100 USD $1.15615
≥500 USD $1.11815
≥1000 USD $1.0811
Inventory: 3924
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Tolerance ±30%
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Temperature Coefficient 800 ppm/°C
Resistance 50kOhm
Number of Positions 128
Additional Feature ALSO OPERATES AT 5V SUPPLY
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number AD5220
Pin Count 8
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Power Supplies 3/5V
Configuration Potentiometer
Interface Up/Down (U/D, CS)
Number of Circuits 1
Operating Supply Current 15μA
Nominal Supply Current 15μA
Memory Type Volatile
Max Supply Current 15μA
Quiescent Current 15μA
Bandwidth 0.142 kHz
Taper Linear
-3db Bandwidth 650 kHz
Number of Taps 128
Total Resistance 50000Ohm
Resistance - Wiper (Ω) (Typ) 40
Dimensions
Height 1.1mm
Length 3.2mm
Width 3.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
