AD5220BNZ100
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
ROHS3Compliant CMOS DUAL Through Hole Digital Potentiometer ±30% -40C~85C 15muA 3.43mm
PDF
/
Buying Options
Total Price: USD $4.73
Unit Price: USD $4.7344
≥1 USD $4.7344
≥10 USD $4.25216
≥100 USD $4.019664
≥500 USD $3.483656
≥1000 USD $3.304998
≥3000 USD $2.965565
Inventory: 386
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.24mm
Length 9.27mm
Height 3.43mm
Technical
Resistance - Wiper (Ω) (Typ) 40
Total Resistance 100000Ohm
Number of Taps 128
-3db Bandwidth 650 kHz
Taper Linear
Bandwidth 0.069 kHz
Quiescent Current 15μA
Max Supply Current 15μA
Memory Type Volatile
Operating Supply Current 15μA
Interface Up/Down (U/D, CS)
Configuration Potentiometer
Power Supplies 3/5V
Number of Elements 1
Operating Supply Voltage 5.5V
Pin Count 8
Base Part Number AD5220
Terminal Pitch 2.54mm
Supply Voltage 3V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology CMOS
Additional Feature ALSO OPERATES AT 5V SUPPLY
Number of Positions 128
Resistance 100kOhm
Temperature Coefficient 800 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Tolerance ±30%
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 930.006106mg
Number of Pins 8
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 8 Weeks
