AD5161BRM100
RoHS
/
Package 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
Non-RoHS Compliant GULL WING Surface Mount Surface Mount Digital Potentiometer ±30% -40C~125C 3muA 3mm
PDF
/
Buying Options
Total Price: USD $14.25
Unit Price: USD $14.25492
≥1 USD $14.25492
≥10 USD $13.448039
≥100 USD $12.686831
≥500 USD $11.968707
≥1000 USD $11.291236
Inventory: 1098
Minimum: 1
-
+
Technical Details
Technical
Pin Count 10
Power Supplies 3/5V
Configuration Potentiometer
Interface I2C, SPI
Number of Circuits 1
Nominal Supply Current 3μA
Memory Type Volatile
Max Supply Current 3μA
Quiescent Current 3μA
Bandwidth 0.04 kHz
Taper Linear
Number of Taps 256
Total Resistance 100000Ohm
Resistance - Wiper (Ω) (Typ) 50
Resistor Terminal Voltage-Max 3V
Temperature Coefficient (Typ) 45ppm/°C
Base Part Number AD5161
Time@Peak Reflow Temperature-Max (s) 30
Frequency 25MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Number of Positions 256
Resistance 100kOhm
Temperature Coefficient 35 ppm/°C
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Cascade Pin, Selectable Address
JESD-609 Code e0
Tolerance ±30%
Packaging Tube
Operating Temperature -40°C~125°C
Dimensions
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Number of Pins 10
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Lead, Tin
