TLV1549CDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Analog to Digital Converters (ADC)
Description
8-SOIC (0.154 3.90mm Width) TLV1549 ACTIVE (Last Updated: 1day ago) Nickel/Palladium/Gold (Ni/Pd/Au) analog digital converter 1.58mm 400muA 38ksps 1.32mW
PDF
/
Buying Options
Total Price: USD $4.85
Unit Price: USD $4.8469
≥1 USD $4.8469
≥10 USD $3.9767
≥100 USD $3.85225
≥500 USD $3.72875
≥1000 USD $3.6043
Inventory: 1179
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Min Supply Voltage (DC) 3V
Max Supply Voltage (DC) 3.6V
Output Format SERIAL
Ratio - S/H:ADC 1:1
Conversion Rate 38 ksps
Number of Converters 1
Sample and Hold / Track and Hold SAMPLE
Integral Nonlinearity (INL) 1 LSB
Linearity Error-Max (EL) 0.0977%
Power Consumption 1.05mW
Output Bit Code BINARY
Sampling Rate (Per Second) 38k
Number of Analog In Channels 1
Voltage - Supply, Digital 3V~3.6V
Voltage - Supply, Analog 3V~3.6V
Sampling Rate 38 ksps
Resolution 1.25 B
Data Interface SPI
Reference Type External
Supply Type Single
Converter Type ADC, SUCCESSIVE APPROXIMATION
Architecture SAR
Input Type Single Ended
Number of Bits 10
Nominal Supply Current 400μA
Configuration S/H-ADC
Operating Supply Voltage 3.6V
Qualification Status Not Qualified
Pin Count 8
Base Part Number TLV1549
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 1.32mW
Subcategory Analog to Digital Converters
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
